100-9613.00-00002 (LH) 90° Rod redirect adapter. Pack of 10
100-9613.00-00002 90° Rod redirect adapter for multi-point locking system (LH version). Pack of 10.
- For Quarter-Turns with insert GL 18mm and swinghandles for round rods Ø8mm.
- Materials: Redirect: zinc die, zinc plated. C-clip and setscrew: steel, zinc plated.
- RH and LH versions available.
- Multiple latching points in one closing process.
- Pack of 10.
Notes:
1. Cam position
2. On the back side of the redirect cam position turned 90°
3. Assembly spacer on weld-stud M6x32
c) Adapter for round rods (must be ordered by using round rods)
d) H-dimension 18mm only for sheet thickness 2mm
f) For the use of flat rods please contact us
2. On the back side of the redirect cam position turned 90°
3. Assembly spacer on weld-stud M6x32
c) Adapter for round rods (must be ordered by using round rods)
d) H-dimension 18mm only for sheet thickness 2mm
f) For the use of flat rods please contact us
For full datasheet see below.
Please contact us for large quantities.
